- 🎁Super Light: Made of plastic gear, Coreless motor, only 3.7g.
- 🎁Torque: 0.6kg/cm (at 3.6V) 0.8kg/cm(at 4.8V), Operating Speed: 0.13sec/60degree(at 3.6V) 0.09sec/60 degree(at 4.8V)
- 🎁Cable length 150mm, Black is negative, red is positive, white is signal line. Working voltage: 3.6-4.8V
- 🎁The RC servo can be used for RC Car, DIY，drone, or airplane helicopter.
- 🎁The model servo has High efficiency, low noise and low power consumption during operation.
Overview:
The item is a set of 1pcs simple and practical mini 3.7g micro servos with accessories, which are mainly made of durable hard plastic, and suitable for RC plane, helicopter, boat and car.
It is spuer light.It comes with a 3-pin power and control cable and mounting hardware.
With easy to install and use, it is really a wonderful RC micro servos for choice.
Specification of servo GH-S37D:
Torque : 0.6kg/cm (at 3.6V) 0.8kg/cm(at 4.8V)
Operating Voltage : 3.6-4.8V
Operating Speed : 0.13sec/60degree(at 3.6V) 0.09sec/60 degree(at 4.8V)
Motor Type: hollow cup
Operating Temperature: 0-60 Celsius
Teeth Material: Plastic
Standard Signal: 1000 to 2000 microseconds
Temperature Range : 0~ 60℃
Working Degree: 90 degree
Current: <350mA
Dead Zone Setting: 3 usec
Cable Length : 150mm
Weight: 3.7g
Size: 20X8.75X22mm
Servo Type: Digital Servo
